Combo Package- BendPak HDS-14X
Choose options to update the price
Combo Package Includes: BendPak HDS-14X Extended Length 14,000lb. Capacity Lift, and one RBJ-7 7,000lb. Capacity Rolling Jack and Airline Kit
The "limo style" HDS14X lift is useful for vehicles that make use of its 229" runways. Limousines, as well as heavy-duty SUVs and trucks, need the extra length, and that’s where this heavy-duty four-post lift comes in handy. With it's 14,000-lb. lifting capacity, long runways and ample 70" rise, the HDS-14X allows most mechanics to stand upright to perform oil changes, exhaust service, wheel service and every other undercarriage activity. Add-on the optional drive-thru ramps and drip trays and you've got a lift that will leave others envious.
Manuals
<h2 style="box-sizing: inherit; margin: 0px 0px 0.67em; color: rgb(76, 76, 76); font-family: "Titillium Web", Muli, sans-serif; background-color: rgb(255, 255, 255);">Features</h2><ul style="font-size: 16px; box-sizing: inherit; margin: 0px 0px 1.5em; list-style-position: initial; list-style-image: initial; color: rgb(76, 76, 76); font-family: "Titillium Web", Muli, sans-serif; background-color: rgb(255, 255, 255);"><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">14,000-lb. lifting capacity</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Mid to long-style approach ramps for low ground clearance vehicles</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Runways include rail-kit for optional accessories</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Single hydraulic cylinder mounted underneath runway</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Fully enclosed lifting cables, safety locks and sheaves</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Internal anti-sway slider blocks in each column</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Pneumatic push-button safety release</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Features heavy-duty 1/2" aircraft cable</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Safety locks enclosed in columns minimize pinch points</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Oversized sheave diameter reduces cable fatigue</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Oversized self-lubricating cable rollers</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Rugged 1.75" roller axles</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Multi-position safety locks in each column</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Customizable power unit location</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Approach ramps incorporate built-in rear-wheel chocks</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Independent backup slack-cable safety latches</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Runways feature non-skid surface</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Optional drive-thru ramps available</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Optional drip trays available</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">Optional 7,000-lb. capacity rolling jacks available (Model RBJ7000)</li><li style="box-sizing: inherit; margin: 0px 0px 1em 1.5em;">ETL approved</li></ul>
<h2 style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);font-family:"Titillium Web", Muli, sans-serif;margin:0px 0px 0.67em;text-align:center;">
HDS-14X Specifications
</h2>
<p style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);font-family:"Titillium Web", Muli, sans-serif;margin:0px 0px 0.67em;text-align:center;">
<i>*This diagram is intended for illustrative purposes only and should not be construed as an authoritative representation of the actual product, system or design. </i>
</p>
<p>
<img class="spec-image" style="background-color:rgb(255, 255, 255);border-width:0px;box-sizing:inherit;color:rgb(76, 76, 76);font-family:"Titillium Web", Muli, sans-serif;font-size:16px;height:auto;max-width:100%;vertical-align:middle;" src="https://cdn.shopify.com/s/files/1/0697/9741/3106/files/BendPak-HDS-14-Series-Specifications-Diagram_babco.jpg?v=1723192471" alt="HDS-14X specs diagram">
</p>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Capacity
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>Lifting Capacity*</strong>
</div>
<div class="spec-value pounds" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
14,000 lbs. (6,350 kg)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>*Max Capacity / Front Axle</strong>
</div>
<div class="spec-value pounds" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
7,000 lbs. (3,175 kg)
</div>
</div>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>*Max Capacity / Rear Axle</strong>
</div>
<div class="spec-value pounds" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
7,000 lbs. (3,175 kg)
</div>
</div>
</div>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Rise
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>A</strong></span></span><strong> - Min. Runway Height:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
7.625" (194 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>B</strong></span></span><strong> - Max. Rise:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
70" (1,778 mm)
</div>
</div>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>C</strong></span></span><strong> - Max. Lifting Height:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
77.625" (1,972 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>Time to Full Rise:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
60 seconds
</div>
</div>
</div>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Outside Dimensions
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>D</strong></span></span><strong> - Overall Width:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
130" (3,302 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>E</strong></span></span><strong> - Outside Length:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
243" (6172 mm)
</div>
</div>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>F</strong></span></span><strong> - Overall Length:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
271" (6,883 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>G</strong></span></span><strong> - Height of Columns:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
93" (2,362 mm)
</div>
</div>
</div>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Inside Dimensions
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>H</strong></span></span><strong> - Width Between Columns:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
120" (3,048 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>I</strong></span></span><strong> - Drive-Thru Clearance:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
98" (2,489 mm)
</div>
</div>
</div>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Runways
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>J</strong></span></span><strong> - Runway Width:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
20" (508 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>K</strong></span></span><strong> - Length of Runways:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
229" (5,817 mm)
</div>
</div>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>L</strong></span></span><strong> - Width Between Runways:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
<span class="inches" style="box-sizing:inherit;">37.5" (953 mm)</span> or <span class="inches" style="box-sizing:inherit;">51" (1,295 mm)</span>
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>M</strong></span></span><strong> - Runway Centerline:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
<span class="inches" style="box-sizing:inherit;">57.5" (1,461 mm)</span> or <span class="inches" style="box-sizing:inherit;">71" (1,803 mm)</span>
</div>
</div>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<span style="color:rgb(171,24,38);"><span class="red" style="box-sizing:inherit;"><strong>N</strong></span></span><strong> - Outside Edge of Runways:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
<span class="inches" style="box-sizing:inherit;">77.5" (1,969 mm)</span> or <span class="inches" style="box-sizing:inherit;">91" (2,311 mm)</span>
</div>
</div>
</div>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Minimum Wheelbase
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>Rated Capacity:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
165" (4,191 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>75% Capacity:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
140" (3,556 mm)
</div>
</div>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>50% Capacity:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
115" (2,921 mm)
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>25% Capacity:</strong>
</div>
<div class="spec-value inches" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
95" (2,413 mm)
</div>
</div>
</div>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Locking
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>Locking Positions:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
13
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>Lock Spacing:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
Every 4" (102 mm)
</div>
</div>
</div>
<div class="spec-block" style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);display:table;font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:2em auto;width:512px;">
<h3 style="box-sizing:inherit;margin:0px 0px 0.67em;">
Power Unit
</h3>
<div class="spec-row" style="background-color:rgb(238, 238, 238);box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>Motor:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
220 VAC / 60 Hz / 1 Ph
</div>
</div>
<div class="spec-row" style="box-sizing:inherit;display:table-row;">
<div class="spec-label" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0px 10px 1em;width:230px;">
<strong>Noise:</strong>
</div>
<div class="spec-value" style="box-sizing:inherit;display:table-cell;font-size:0.875em;padding:10px 0.75em 10px 0px;">
45 dB
</div>
</div>
</div>
<p style="background-color:rgb(255, 255, 255);box-sizing:inherit;color:rgb(76, 76, 76);font-family:"Titillium Web", Muli, sans-serif;font-size:16px;margin:0px 0px 25px;">
<span style="box-sizing:inherit;"><strong>Note:</strong></span> An air supply (minimum: 30 psi / 3 CFM) is required for the safety-lock mechanisms to disengage. It is solely the responsibility of the end-user to provide, install and maintain the air supply.
</p>
